OpenAPI documentation — generating docs from your Express API

API Documentation with OpenAPI and Swagger UI

OpenAPI (formerly Swagger) is the industry standard for REST API documentation. It produces an interactive UI where developers can read specs and test endpoints in-browser.

Setup

npm install swagger-ui-express swagger-jsdoc

// config/swagger.js
const swaggerJsdoc = require('swagger-jsdoc');

const options = {
  definition: {
    openapi: '3.0.0',
    info: { title: 'My API', version: '1.0.0' },
    components: {
      securitySchemes: {
        bearerAuth: { type: 'http', scheme: 'bearer', bearerFormat: 'JWT' }
      }
    }
  },
  apis: ['./routes/*.js'] // files with JSDoc annotations
};

module.exports = swaggerJsdoc(options);

Annotating Routes

/**
 * @openapi
 * /users/{id}:
 *   get:
 *     summary: Get a user by ID
 *     security:
 *       - bearerAuth: []
 *     parameters:
 *       - in: path
 *         name: id
 *         required: true
 *         schema:
 *           type: integer
 *     responses:
 *       200:
 *         description: User object
 *       404:
 *         description: User not found
 */
router.get('/:id', authenticate, getUser);

// Mount Swagger UI
const swaggerUi = require('swagger-ui-express');
const specs = require('./config/swagger');
app.use('/api-docs', swaggerUi.serve, swaggerUi.setup(specs));
